China Wire Rope Sling manufacturer

304 316 Stainless Steel Wire Rope Flexible 7 X 37 For Marine / Uplifting

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: CE / ISO9001:2008
Model Number: 7x37
Payment & Shipping Terms:
Minimum Order Quantity: 1mtrs
Price: USD5000/TON
Packaging Details: Seaworthy packing or as request
Delivery Time: 15 days after the order confirmation
Payment Terms: L/C, T/T
Supply Ability: 100tons monthly

Detail Information

Steel Grade:300 SeriesStandard:AISI, ASTM, BS, DIN, GB, JIS
Wire Gauge:0.1mm-58 MmType:Drawn Wire,Carbon Steel Wire
Alloy Or Not:Non-alloySpecial Use:Cold Heading Steel
Certificate:ISO, SGSPackaging:In Coil And Pallet
High Light:

coated stainless steel cable

,

stainless steel cable

Product Description



Stainless Steel 1x19 Wire Rope EN12385-4 for Marine / Lifting AISI304 / 316

Product Details

6x37 is the most flexible of our stainless steel wire ropes. Available in much larger diameters, 6x37 stainless steel wire ropes are often used for larger diameter stainless steel slings as well as for general engineering applications. The wire rope has an equal lay construction (warrington seale) and achieves a superior breaking load to the 6x19 construction range. 6x37 construction has been designed to give a flexible rope with a good fatigue life. 6x37 wire rope is available with either FC (fibre core) or IWRC (independent wire rope core) and is used for a wide range of applications, including:

  • Applications
  • Marine crane rope applications
  • Luffing ropes
  • Lifeboat falls
  • Davit ropes
  • Large diameter stainless steel wire rope slings
  • Marine/Saltwater environment
  • Sewage treatment works
SupplyAbility

SupplyAbility:

800 Ton/Tons per Month

Packaging & Delivery

Packaging Details

500m/reel, 1000m/reel, 2000m/reel, 5000m/reel, etc.
Inner packing:
Wooden reel and craft paper
Outer packing:
Wooden pallet or according to requests

Port

Shanghai

Lead Time :

15 working days



304 stainless steel cable 316 ss welding wire 7x37

Product Description

Wire Rope

7x37 Stainless Steel Cable Specification:

Structure Norminal diameter mm Approximate Weight kg/1000m Min. Breaking Strength N Min. Breaking Strength kg
7x37 10 400 54000 5510
12 576 73000 7449
13 676 82000 8367
14 784 89000 9082
16 1024 124000 12653
18 1296 157000 16020
20 1600 194000 19796
22 1936 235000 23980
24 2304 280000 28571
26 2704 328000 33469
28 3136 381000 38878
30 3600 437000 44592
32 4096 497000 50714

other diameter and structure available



Stainless Steel Wire Rope



Chemical Composition of common Stainless Steel
%
Component C Si Mn P S Cr Ni Mo
304 MAX 0.08 MAX 1.00 MAX 2.00 MAX 0.045 MAX 0.03 17.00-19.00 8.00-10.00
304L MAX 0.03 MAX 1.00 MAX 2.00 MAX 0.045 MAX 0.03 18.00-20.00 8.00-10.00
316 MAX 0.08 MAX 1.00 MAX 2.00 MAX 0.045 MAX 0.03 16.00-18.00 10.00-14.00 2.00-3.00
316L MAX 0.03 MAX 1.00 MAX 2.00 MAX 0.045 MAX 0.03 16.00-18.00 12.00-15.00 2.00-3.00





Packaging & Shipping

 304 316 Stainless Steel Wire Rope Flexible 7 X 37 For Marine / Uplifting 2
