Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: CCS,ISO9001
Model Number: LKS 16-6
Payment & Shipping Terms:
Minimum Order Quantity: 1mtrs
Price: USD1800/tons
Packaging Details: Standard Seaworthy Packing or as request
Delivery Time: 15 days after the order confirmation
Payment Terms: L/C, T/T
Supply Ability: 100tons monthly

Detail Information

Product Name:Hosting Wire RopeSurface:Galvanized/Ungalvanized
Length:500mtrs/1000mtrs/2000mtrs AvailableDiameter:8mm-60mm
Core:Wire StrandHS Code:73121000
Standard:GB/DIN/BS/JIS/ASTM/RR-W-410/API/ISOPacking:Wooden Reel
High Light:

wire rope cable

,

steel rope cable

Product Description



 Rotating Tower Crane Hoisting Steel Wire Rope LKS 16-6 Rotation-resistant

ROTATION-RESISTANT ROPES SINCE 1949

In a conventional rope, an external load creates a torsional moment which tries to un-twist the rope. A rotation resistant steel wire rope has a steel core which is an independent rope, closed in the opposite direction to the outer strands. Under load, the core tries to twist the rope in one direction, the outer strands try to twist it in the opposite direction. The geometrical design of a rotation resistant wire rope is such that the torsional
moments in the core and the outer strands compensate each other over a wide load spectrum, so that even with great lifting heights practically no rope twist occurs.





Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 0

  • Rope category number (RCN) 23-2 according to ISO 4309
  • EN 12385-3
  • Lang lay
  • Zinc-coated class B standard
  • Rotation-resistant (a) EN 12385-3
  • Can be used with swivel
  • Special lubrication

The new LKS 16-6 is a rotation-resistant hoisting rope of class a. Like the LKS 16-1 (LKSS 35), it features the tried and true 16 outer strands of 7 wires each. The interior construction is made of 3 strands that are supported by 3 thinner fill strands in...

ATTRIBUTES

Can be used with swivel Fettung


APPLICATIONS

Lattice boom crane - Main hoisting rope Harbour crane - Hoisting rope Offshore crane - Hoisting rope Mobile crane - Hoisting rope ​Rotating tower crane - Hoisting rope







Technical Data




Ø   Weight Metallic
cross-section
MBK 1960 MBK 2160
mm   kg/100m mm2 kN kN
8   29.1 32.0 47.7 52.5
9   36.9 40.5 60.3 66.5
10   45.5 50.0 74.5 82.1
11   55.1 60.5 90.1 99.0
12   65.5 72.0 107 118
13   76.9 84.5 126 139
14   89.2 98.0 146 161
15   102 113 168 186
16   116 128 191 210
17   131 145 216 238
18   147 162 241 266
19   164 181 270 297
20   182 200 298 328







 CRANE TYPES AND WIRE ROPES





BRIDGE CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 8

orange = hoisting rope
green = trolley rope



TELESCOPING CRANERotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 9

orange = hoisting rope
green = telescope rope



GANTRY CRANE (RTG/RMG)Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 10

orange = hoisting rope
green = trolley rope



STRADDLE CARRIER

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 11

orange = hoisting rope







LATTICE BOOM CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 12

orange = hoisting rope
yellow = auxiliary hoisting rope
blue = boom pendant rope and adjusting rope

HARBOUR CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 13

orange = hoisting rope
blue = boom pendant rope and adjusting rope





OFFSHORE CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 14

orange = hoisting rope
blue = boom pendant rope and adjusting rope

MOBILE CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 15

orange = hoisting rope
blue = boom pendant rope and adjusting rope

REVOLVING TOWER CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 16

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = assembly rope

EXCAVATING BUCKET / SCRAPERSRotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 17

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = backhaul rope

GRABBING CRANE

Rotating Tower Crane Hoisting Coated Wire Rope LKS 16-6 Rotation Resistant 18

orange = hoisting rope
blue = boom pendant rope and adjusting rope
yellow = closing rope





Crane wire ropes play an important role in ensuring a smooth conduct of work processes in harbors, off-shore platforms or various other applications where cranes are needed. Whether you need tower crane ropes or offshore crane ropes, galvanized or stainless steel ropes, you will find the optimal solution in our company.
