Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: CCS,ISO9001
Model Number: LKS 8-2 CP
Payment & Shipping Terms:
Minimum Order Quantity: 1mtrs
Price: USD1800/tons
Packaging Details: Standard Seaworthy Packing or as request
Delivery Time: 15 days after the order confirmation
Payment Terms: L/C, T/T
Supply Ability: 100tons monthly

Detail Information

Product Name:Crane Wire RopeSurface:Galvanized/Ungalvanized
Length:500mtrs/1000mtrs/2000mtrs AvailableDiameter:6mm-60mm
Core:Plastic Padding Wire RopeHS Code:73121000
Standard:GB/DIN/BS/JIS/ASTM/RR-W-410/API/ISOPacking:Wooden Reel
High Light:

wire rope cable

,

steel rope cable

Product Description



Lattice boom Crane boom pendant Steel Wire Rope LKS 8-2 CP Plastic padding

Crane wire rope can be used for main hoist rope, boom rope, derrick rope, closing rope, grab rope, hoist rope, tower erection rope, boom rope and trolley rope. Matching the ideal rope for your type of crane and application is not so easy because no single rope will fit all requirements; for example no one rope is fatigue resistant, crush resistant, abrasion resistant, rotation resistant, have the necessary breaking strength, rope diameter and/or rope structure stability, so choosing the right rope may require a little research.





Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 0



  • Rope category number (RCN) 09¹⁾(up to ø 38 mm), 11²⁾ (up to ø 44 mm), 13³⁾ (up to ø 48 mm) according to ISO 4309
  • Ordinary lay
  • Zinc-coated class B standard
  • Should not used with a swivel
  • Special lubrication
  • Outer strands compacted
  • Plastic padding


Compacted • 8-Strand • Inner Plastified Wire ropes

This wire rope belongs in the non rotation resistant classification but its strands are compacted and it is used mainly as luffing wire rope on high efficiency ship & harbour mobile cranes, container bridge cranes, overhead travelling hoists, mineral loading cranes.

It is an 8-strand construction, very flexible and suitable for use on many crane brands installed on board.

These wire ropes are usually produced as drawn galvanized and internally and externally lubricated, which makes them corrosion resistant and durable against the various harsh marine environment factors.

8-strand Compacted Wire RopeAdditionally, these ropes are produced with an extruded inner plastic layer, which ensures water impermeability and elimination of point contact between wires & strands of the inner and outer layers.

This extra protection from corrosion and inner contact, prolongs the useful service life of the ropes.

Attention must be paid in the installation of the new rope on board, its running-in (bedding in) period and load and the inspection before and after every usage.

Diligent production processes, raw material selection and quality control in all stages of production ensure a long and trouble free service life.

ATTRIBUTES

Plastic padding ​Fettung Compressed


APPLICATIONS

Bridge crane - Hoisting rope Gantry crane (RTG/RMG) - Hoisting rope Straddle carrier - Hoisting rope Container crane (STS) - Hoisting rope Lattice boom crane - Boom pendant rope and adjusting rope Harbour crane - Boom pendant rope and adjusting rope Offshore crane - Boom pendant rope and adjusting rope Mobile crane - Hoisting rope ​Gripper crane - Hoisting rope







Technical Data
Nominal diameter Approx. weight Minimum breaking load
1770N/mm² 1960N/mm² 2160N/mm²
mm Kg/m kN
10 0.46 79 87 96
11 0.55 95 105 115
12 0.69 114 126 139
13 0.81 137 152 168
14 0.93 159 176 194
15 1.06 182 201 222
16 1.20 206 229 252
17 1.35 233 258 284
18 1.55 260 288 318
19 1.71 294 326 359
20 1.89 324 359 395
21 2.15 363 401 442
22 2.34 396 439 484
23 2.54 433 480 529
24 2.75 462 512 564
25 2.97 508 562 620
26 3.19 546 605 667
27 3.51 588 651 717
28 3.76 640 708 781
28.6 3.90 659 730 804
29 4.03 682 755 832
30 4.30 740 819 903
32 4.90 842 932 1027
34 5.59 936 1036 1142
36 6.26 1055 1168 1287
38 6.96 1195 1323 1458
40 7.71 1312 1453 1601
42 8.45 1449 1604 1768
44 9.27 1573 1742 1920






 CRANE TYPES AND WIRE ROPES





BRIDGE CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 14

orange = hoisting rope
green = trolley rope



TELESCOPING CRANELattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 15

orange = hoisting rope
green = telescope rope



GANTRY CRANE (RTG/RMG)Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 16

orange = hoisting rope
green = trolley rope



STRADDLE CARRIER

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 17

orange = hoisting rope







LATTICE BOOM CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 18

orange = hoisting rope
yellow = auxiliary hoisting rope
blue = boom pendant rope and adjusting rope

HARBOUR CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 19

orange = hoisting rope
blue = boom pendant rope and adjusting rope





OFFSHORE CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 20

orange = hoisting rope
blue = boom pendant rope and adjusting rope

MOBILE CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 21

orange = hoisting rope
blue = boom pendant rope and adjusting rope

REVOLVING TOWER CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 22

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = assembly rope

EXCAVATING BUCKET / SCRAPERSLattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 23

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = backhaul rope

GRABBING CRANE

Lattice Boom Crane Boom Pendant 8mm Wire Rope LKS 8-2 CP Plastic Padding 24

orange = hoisting rope
blue = boom pendant rope and adjusting rope
yellow = closing rope





Crane wire ropes play an important role in ensuring a smooth conduct of work processes in harbors, off-shore platforms or various other applications where cranes are needed. Whether you need tower crane ropes or offshore crane ropes, galvanized or stainless steel ropes, you will find the optimal solution in our company.
