Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | LKS |
| Certification: | CE / ISO9001:2008 |
| Model Number: | 6X7+FC |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1mtrs |
| Price: | USD5000/TON |
| Packaging Details: | Seaworthy packing or as request |
| Delivery Time: | 15 days after the order confirmation |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100tons monthly |
|
Detail Information |
|||
| Steel Grade: | 300 Series | Standard: | AISI, ASTM, BS, DIN, GB, JIS |
|---|---|---|---|
| Wire Gauge: | 0.6mm-10mm | Type: | Drawn Wire,Carbon Steel Wire |
| Alloy Or Not: | Non-alloy | Special Use: | Cold Heading Steel |
| Certificate: | ISO, SGS | Packaging: | In Coil And Pallet |
| High Light: |
coated stainless steel cable,stainless steel cable |
||
Product Description
1.Construction: 6x7+FC
2.Tensile Strength: 1570 Mpa, 1670 Mpa, 1770 Mpa, 1960 Mpa.
3.Diameter: 0.2mm - 50mm
4.Standard:DIN, GB, EN12385-4, AISI, BS, ASTM, JIS etc
5.ISO and SGS certificates.
6.Delivery date:10-30days after the order confirmation.
7.Packing: wooden reel and craft paper , wooden pallet, or as you required.
The smallest component of a rope.
The element of a rope that is composed of a construction of wires which are helically stranded in the same direction in one or more layers around a core.
The element in the middle of a round rope, around which the strands of a stranded rope or the ropes of a cable laid rope are helically stranded.
Fibre core FC
Steel core WC
Combination of core and strands.
1 - Rope
2 - Core strand/rope
3 - Strand
4 - Wire
Ropes that run over rollers, discs or reels and thus assume their bend.
Examples: hoisting ropes, crane ropes, lift ropes, scraper ropes and haulage ropes for cable cars.
Ropes which are for the most part firmly clamped and not moved over rollers.
Examples: anchoring ropes for masts and booms and guide cables for lifts.
Ropes on which rolls of conveying devices run.
Examples: carrying ropes for cable cars, cable cranes and gravity return scrapers.
Ropes which are used to suspend loads.
Approx.Weight
| Diameter(mm) | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 16 |
| kg/1000m | 14.0 | 31.5 | 56.0 | 87.5 | 126.0 | 171.5 | 224 | 283.5 | 350 | 423.5 | 504 | 591.5 | 686 | 896 |
Main products:
Stainless steel wire/rope, galvanized steel wire/rope, PVC/PE/Nylon coated steel rope, link chain, slings, parts of steel wire rope, etc.
Product Application:
Stainless steel wire rope Mainly used for decoration, chemical metallurgy, petroleum machinery, port machinery, nuclear industry, the coal, metallurgy, chemicals, shipbuilding, bridges, electricity, rubber, military, tourism, water, light industry, aviation and aerospace industry.
Packaging
Packing: Export Package
Inner packing:
Wooden reel and craft paper
Outer packing:
Wooden pallet or according to customer's request
