M246 Wire Rope Cable Clamps High Precision Customized For Fastening Wire Rope

• A great, cost-competitive option compared to other name brand clips
• Base is made from drop forged steel
• Precision manufactured and galvanized to meet Federal Specifications (FF-C-450 Type 1 Class 1) on sizes 1/4" and larger
• Orange U-bolt to distinguish CM brand

Proper use of Wire Rope Clips

1. Refer to the illustration below in following these instructions. Turn back specified amount of rope from thimble or loop. Apply first clip on base width from dead end of rope. Apply U-bolt over dead end of wire rope – live end rests in saddle. Tighten nuts evenly, alternate from one nut to the other until reaching the recommended torque.
2. When two clips are required, apply the second clip as near the thimble or loop as possible. Tighten nuts evenly, alternating until reaching the recommended torque. When more than two clips are required, apply the second clip as near the loop or thimble as possible, turn nuts on second clip firmly, but do not tighten. Proceed to Step 3.
3. When three or more clips are required, space additional clips equally between the first two – take up rope slack – tighten nuts on each U-bolt evenly, alternating from one nut to the other until reaching the recommended torque.
4. Apply initial load equal to loads expected in use. Inspect for proper orientation and spacing of clips and retighten the nuts to recommended torque.

Packaging Details

1.packaged by bag or carton with pallet
2..small sizes usually is 100pcs/bag, largest is 4/carton.
3.a 20 ft container can accept about 22t goods.
Special requirements in package can be met.

Delivery Time

7-35days according to different quantity
