Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: CCS,ISO9001
Model Number: LKS 16-5 C
Payment & Shipping Terms:
Minimum Order Quantity: 1mtrs
Price: USD1800/tons
Packaging Details: Standard Seaworthy Packing or as request
Delivery Time: 15 days after the order confirmation
Payment Terms: L/C, T/T
Supply Ability: 100tons monthly

Detail Information

Product Name:Hosting Wire RopeSurface:Galvanized/Ungalvanized
Length:500mtrs/1000mtrs/2000mtrs AvailableDiameter:8mm-60mm
Core:Wire StrandHS Code:73121000
Standard:GB/DIN/BS/JIS/ASTM/RR-W-410/API/ISOPacking:Wooden Reel
High Light:

wire rope cable

,

steel rope cable

Product Description



Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All strands compacted



Crane ropes must be especially durable and capable of bearing loads. Adverse weather conditions, quickly changing loads and high loads test the rope to the extreme. LKS provides you with an extensive program of high-performance ropes for all common crane applications.
Our product program includes both rotation-resistant constructions and non-rotation-resistant constructions.
Furthermore, we offer ropes compacted using various methods and with various degrees of compaction.
Additional plastic padding improves the shape stability of the rope and prevents premature wear from appearing in the interior of the rope.



Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 0

  • Rope category number (RCN) 23-2 according to ISO 4309
  • EN 12385-3
  • Lang lay
  • Zinc-coated class B standard
  • Rotation-resistant (a) EN 12385-3
  • Can be used with swivel
  • Special lubrication
  • All strands compacted

The tried and true LKS 16-5 C (LKSK 35) with 35 compacted strands of 7 wires each features very high breaking forces due to the high degree of compaction

ATTRIBUTES

Can be used with swivel Fettung Compressed


APPLICATIONS

Telescopic crane - Hoisting rope Lattice boom crane - Main hoisting rope Harbour crane - Hoisting rope Offshore crane - Hoisting rope Mobile crane - Hoisting rope ​Rotating tower crane - Hoisting rope







Technical Data


Ø   Weight Metallic
cross-section
MBK 1960 MBK 2160
mm   kg/100m mm2 kN kN
8   32.6 37.2 59.4 63.8
9   41.3 47.1 75.2 80.8
10   51.0 58.1 92.8 100
11   61.7 70.3 112 121
12   73.4 83.6 134 144
13   86.2 98.2 157 169
14   100 114 182 196
15   115 131 209 224
16   131 149 238 255
18   165 188 301 323
20   204 232 371 399
22   247 281 449 483
24   294 335 534 575
26   345 393 627 674
28   400 455 727
30   459 523 835




 CRANE TYPES AND WIRE ROPES





BRIDGE CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 10

orange = hoisting rope
green = trolley rope



TELESCOPING CRANELattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 11

orange = hoisting rope
green = telescope rope



GANTRY CRANE (RTG/RMG)Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 12

orange = hoisting rope
green = trolley rope



STRADDLE CARRIER

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 13

orange = hoisting rope







LATTICE BOOM CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 14

orange = hoisting rope
yellow = auxiliary hoisting rope
blue = boom pendant rope and adjusting rope

HARBOUR CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 15

orange = hoisting rope
blue = boom pendant rope and adjusting rope





OFFSHORE CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 16

orange = hoisting rope
blue = boom pendant rope and adjusting rope

MOBILE CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 17

orange = hoisting rope
blue = boom pendant rope and adjusting rope

REVOLVING TOWER CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 18

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = assembly rope

EXCAVATING BUCKET / SCRAPERSLattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 19

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = backhaul rope

GRABBING CRANE

Lattice Boom Crane Hoisting Steel Wire Rope LKS 16-5 C All Strands Compacted 20

orange = hoisting rope
blue = boom pendant rope and adjusting rope
yellow = closing rope





Crane wire ropes play an important role in ensuring a smooth conduct of work processes in harbors, off-shore platforms or various other applications where cranes are needed. Whether you need tower crane ropes or offshore crane ropes, galvanized or stainless steel ropes, you will find the optimal solution in our company.
