Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | LKS |
| Certification: | CE / ISO 9001 : 2008 |
| Model Number: | 7x19PVC |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1mtrs |
| Price: | USD1580/TONS |
| Packaging Details: | Wooden Reel |
| Delivery Time: | 15 days after the order confirmation |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100tons monthly |
|
Detail Information |
|||
| Vinyl Coated: | Yes | Colour: | As Request |
|---|---|---|---|
| Length: | 500m/reel,1000m/reel Or As Request | Material: | Steel |
| Wire Gauge: | 0.9mm-50mm | Standard: | AISI, ASTM, DIN, GB, JIS |
| Steel Grade: | A2-70/A4-80 | HS Code: | 7312100000 |
| High Light: |
vinyl coated wire rope,nylon coated wire rope |
||
Product Description
Galvanized PVC Coated Steel Wire Rope Best partner for Architectural decoration
Wire rope definition
a. Wires: steel wires for wire ropes are normally made of non-alloy carbon steel with a carbon content of 0.4 to 0.95%. The tensile forces and to run over sheaves with relatively small diameters.
b. Strand: the strand is a component of wire rope usually consisting of an assembly of wires of appropriate diamsions laid helically in one or more layers around a central element.
c. Core: the core is the central element, of fiber or steel, around which are laid helically the outer strands of wire rope. The core provides proper support for the strands under normal bending and loading conditions.
d. Wire rope is several strands of metal wire twisted into a helix forming a composite "rope", in a pattern known as "laid rope". Larger diameter wire rope consists of multiple strands of such laid rope in a pattern known as "cable laid".
| Surface treatment | Construction | Diameter (mm) | Tensile Strength |
| 1.Ungalvanized(bright) 2.Electro galvanized 3.Hot dipped galvanized 4.Stainless steel AISI304/316 5.PVC or PE coated |
1x7 | 0.6--14 |
1470N/mm2 OR IPS EIPS EEIPS |
| 1x19 | 1.0--8.0 | ||
| 1x12 | 1.0--8.0 | ||
| 7x7 (6x7+IWRC) | 1.0--20 | ||
| 6x19+IWRC | 3.0--56 | ||
| 6x19W/S+IWRC | 5.0--48 | ||
| 6x37+IWRC | 5.0--84 | ||
| 6x19/25Fi+IWRC | 6.0--54 | ||
| 8x19S/W+IWRC | 8.0--16 | ||
| 8x19S+IWRC | 8.0--16 | ||
| 8x25Fi+IWRC | 16--76 | ||
| 8x31WS+IWRC | 26--80 | ||
| 8x26WS+IWRC | 16--48 | ||
| 8x36WS+IWRC | 22--80 | ||
| 8x41WS+IWRC | 20--60 | ||
| 6x36WS+IWRC | 8.0--78 | ||
| 6x41WS+IWRC | 20--80 | ||
| 6x61WS+IWRC | 20--80 | ||
| 8x37+IWRC | 20--80 | ||
| 8x61+IWRC | 20--80 | ||
| 18x19S+IWRC | 14--40 | ||
| 35Wx7 | 16--40 | ||
| 19x7 | 4.0--60 | ||
| 6x19+FC | 3.0--56 | ||
| 6x19W/S+FC | 6.0--48 | ||
| 6x37+FC | 5.0--84 | ||
| 6x19Fi+FC | 6.0--54 | ||
| 8x19S/W+FC | 8.0--16 | ||
| 8x19S+FC | 6.0--16 | ||
| 8x25Fi+FC | 16--76 | ||
| 8x31WS+FC | 26--80 | ||
| 8x26WS+FC | 16--48 | ||
| 6x36WS+FC | 8.0--78 | ||
| 6x41WS+FC | 20--80 | ||
| 6x61WS+FC | 20--80 | ||
| 8x37+FC | 20--80 | ||
| 8x61+FC | 20--80 | ||
| 18x19S+FC | 14--40 | ||
| 34x7+FC | 16--40 | ||
| 18x7+FC | 4.0--60 | ||
| 6x24+7FC | 6.0--56 | ||
| 6x12+7FC | 3.0--32 |
How does vinyl coating differ from nylon coating?
Nylon is harder than vinyl and has better impact, abrasion, and fatigue resistance than vinyl. Nylon is better suited for friction with pulleys and sheaves. However, vinyl is more flexible and has better UV resistance. Vinyl coating costs less than nylon coating.
What applications does vinyl make sense for?
General purpose, Sailing, Security, Towing, Outdoors (sunny or cold environments)
What are the different constructions of vinyl and nylon coated cable?
Vinyl and nylon coatings are primarily stocked in 7x7 and 7x19 constructions, but other constructions are available upon special request.
1. More than 40 years experience in manufacturing steel wire.
2. High quality of galvanization lines,drawing lines.Some lines are imported from Korea and Italy.
3. Every step will be checked and recorded by quality guys before moving to next step.
4. The payment,delivery,quality all can be guaranteed as per our contract. Trade Assurance by Alibaba will be another guarantee for you.
5. We welcome third-party for inspection,like BV,CCS,SGS.
F.A.Q
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
Q9:You are trade company or manufacturer ?
A:We are manufacturer of cables.
Q10:will you stop produce when government check environment ?
A:No. our company has passed environmental audit .
Our service
1. OEM Manufacturing welcome: Product, Package...
2. Sample free
3. We will reply you for your inquiry in 24 hours.
4. After sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
