Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged
Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: CCS,ISO9001
Model Number: LKS 16-4 CP
Payment & Shipping Terms:
Minimum Order Quantity: 1mtrs
Price: USD1800/tons
Packaging Details: Standard Seaworthy Packing or as request
Delivery Time: 15 days after the order confirmation
Payment Terms: L/C, T/T
Supply Ability: 100tons monthly
Contact Now

Detail Information
Product Name:Hosting Wire RopeSurface:Galvanized/Ungalvanized
Length:500mtrs/1000mtrs/2000mtrs AvailableDiameter:8mm-60mm
Core:Wire StrandHS Code:73121000
Standard:GB/DIN/BS/JIS/ASTM/RR-W-410/API/ISOPacking:Wooden Reel
High Light:

wire rope cable

,

steel rope cable

Product Description



Telescopic Crane Hoisting Steel Wire Rope LKS 16-4 CP Inner rope subsequently swaged



Wire Rope is a Machine

A wire rope is a machine, by dictionary definition: "An assemblage of parts...that transmit forces, motion, and energy one to another in some predetermined manner and to some desired end."

A typical wire rope may contain hundreds of individual wires which are formed and fabricated to operate at close bearing tolerances one to another. When a wire rope bends, each of its many wires slides and adjusts in the bend to accommodate the difference in length between the inside and the outside bend. The sharper bend, the greater the movement.

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 0

  • Rope category number (RCN) 23-2 according to ISO 4309
  • EN 12385-3
  • Inner rope swaged
  • Lang lay
  • Zinc-coated class B standard
  • Rotation-resistant (a) EN 12385-3
  • Can be used with swivel
  • Special lubrication
  • Outer strands compacted
  • Inner rope subsequently swaged
  • Plastic padding

The new LKS 16-4 represents an additional expansion of our product program in the field of crane ropes. The plastic padding of the compacted inner rope can dampen jerky loads and impacts and stabilise the rope structure.

ATTRIBUTES

Plastic padding Can be used with swivel Fettung Compressed​


APPLICATIONS

Telescopic crane - Hoisting rope Lattice boom crane - Main hoisting rope Offshore crane - Hoisting rope Mobile crane - Hoisting rope ​





Technical Data



Ø   Weight Metallic
cross-section		 MBK 1960 MBK 2160
mm   kg/100m mm2 kN kN
8   29.4 32.7 50.6 55.7
9   36.5 41.3 62.4 68.7
10   46.0 51.0 79.0 87.1
11   55.7 61.7 95.6 105
12   66.2 73.5 114 125
13   77.7 86.2 134 147
14   90.2 100 155 171
15   104 115 178 196
16   118 131 202 223
18   149 165 256 282
20   184 204 316 348
22   223 247 382 421
24   265 294 455 502
26   311 345 534 589
28   361 400 619
30   414 459 711






 CRANE TYPES AND WIRE ROPES





BRIDGE CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 9

orange = hoisting rope
green = trolley rope


TELESCOPING CRANETelescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 10

orange = hoisting rope
green = telescope rope


GANTRY CRANE (RTG/RMG)Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 11

orange = hoisting rope
green = trolley rope


STRADDLE CARRIER

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 12

orange = hoisting rope






LATTICE BOOM CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 13

orange = hoisting rope
yellow = auxiliary hoisting rope
blue = boom pendant rope and adjusting rope
HARBOUR CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 14

orange = hoisting rope
blue = boom pendant rope and adjusting rope




OFFSHORE CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 15

orange = hoisting rope
blue = boom pendant rope and adjusting rope
MOBILE CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 16

orange = hoisting rope
blue = boom pendant rope and adjusting rope
REVOLVING TOWER CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 17

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = assembly rope
EXCAVATING BUCKET / SCRAPERSTelescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 18

orange = hoisting rope
blue = boom pendant rope and adjusting rope
green = backhaul rope
GRABBING CRANE

Telescopic Crane Hoisting Metal Wire Rope LKS 16-4 CP Inner Rope Subsequently Swaged 19

orange = hoisting rope
blue = boom pendant rope and adjusting rope
yellow = closing rope





LKS group prides itself on its leading position in the wire rope manufacturing sector, providing the industry with some of the most durable and pioneering technologies available. As a company, we are constantly looking to challenge the boundaries of innovation, not only to exceed customer expectations but also to develop our business into wider markets and geographies.
